通用轴向xb系列波纹管膨胀节(毗连方法可按用户要求)可带外衣 | |||||||||
型号/通径 | 压力mpa波数 | 轴向赔偿量δx mm | 横向赔偿量δy mm | 压力mpa波数 | 轴向赔偿量δx mm | 横向赔偿量δy mm | 压力mpa波数 | 轴向赔偿量δx mm | 横向赔偿量δy mm |
xb40 xb40 | 0.6-9 | 9.2 | 4.7 | 1.0-9 | 9.3 | 4.7 | 1.6-7 | 7.1 | 2.8 |
0.6-17 | 17.3 | 16.4 | 1.0-18 | 18 | 18.5 | 1.6-15 | 15.0 | 12.5 | |
xb50 xb50 | 0.6-6 | 9.9 | 3.6 | 1.0-7 | 11.6 | 4.9 | 1.6-5 | 8.0 | 2.5 |
0.6-12 | 19.6 | 14.2 | 1.0-13 | 21.5 | 16.8 | 1.6-11 | 17.5 | 11.6 | |
xb65 xb65 | 0.6-6 | 16.4 | 5.3 | 1.0-5 | 13.1 | 3.5 | 1.6-5 | 13.0 | 3.4 |
0.6-12 | 32.7 | 20.4 | 1.0-9 | 23.4 | 11.0 | 1.6-9 | 23.3 | 10.9 | |
xb80 xb80 | 0.6-5 | 17.6 | 4.3 | 1.0-4 | 13.2 | 2.6 | 1.6-4 | 13.1 | 2.6 |
0.6-10 | 35.1 | 16.9 | 1.0-8 | 26.4 | 10.2 | 1.6-7 | 22.8 | 7.7 | |
xb100 xb100 | 0.6 -4 | 19 | 3.4 | 1.0-4 | 18.7 | 3.3 | 1.6-5 | 12.7 | 1.7 |
0.6-8 | 37.9 | 13.3 | 1.0-7 | 32.7 | 10.0 | 1.6-11 | 25.3 | 6.7 | |
xb125 xb125 | 0.6-3 | 19.2 | 2.4 | 1.0-3 | 18.8 | 2.3 | 1.6-3 | 11.6 | 1.5 |
0.6-6 | 38.4 | 9.1 | 1.0-6 | 37.4 | 8.9 | 1.6-6 | 23.0 | 5.5 | |
xb150 xb150 | 0.6-4 | 28 | 5.1 | 1.0-4 | 27.6 | 5.1 | 1.6-3 | 19.0 | 2.7 |
0.6-8 | 56 | 20.3 | 1.0-8 | 55.2 | 20.0 | 1.6-6 | 37.0 | 10.3 | |
xb200 xb200 | 0.6-3 | 31.9 | 3.8 | 1.0-3 | 31.1 | 3.7 | 1.6-3 | 23.3 | 2.8 |
0.6-6 | 63.7 | 14.9 | 1.0-5 | 51.7 | 10.1 | 1.6-6 | 46.5 | 11.0 | |
xb250 xb250 | 0.6-3 | 39.7 | 4.7 | 1.0-3 | 32.7 | 4.0 | 1.6-3 | 26.9 | 3.4 |
0.6-6 | 79.2 | 18.7 | 1.0-5 | 54.4 | 11.0 | 1.6-5 | 44.8 | 9.1 | |
xb300 xb300 | 0.6-3 | 44 | 5.1 | 1.0-3 | 40.5 | 4.7 | 1.6-3 | 31.3 | 3.7 |
0.6-6 | 73.3 | 13.9 | 1.0-5 | 67.5 | 12.9 | 1.6-6 | 62.6 | 14.5 | |
xb350 xb350 | 0.6-3 | 52.5 | 6.0 | 1.0-3 | 48.3 | 5.6 | 1.6-3 | 33.5 | 4.0 |
0.6-6 | 87.4 | 16.5 | 1.0-5 | 80.4 | 12.3 | 1.6-5 | 55.8 | 11.0 | |
xb400 xb400 | 0.6-3 | 53.5 | 6.1 | 1.0-3 | 49.1 | 5.7 | 1.6-3 | 39.2 | 4.6 |
0.6-5 | 89.1 | 16.9 | 1.0-5 | 81.8 | 15.6 | 1.6-5 | 65.2 | 12.5 |
